Traffic Control Systems – TCS 3000 Sure-Dock,CYANvisuals

The best protection for your team without the hefty price tagshop safely now!Shop for Traffic Control Systems – TCS 3000 Sure-Dock,CYANvisuals at safetysupplyusa.com.

The TCS 3000 Series outlines the docking area and makes backing up and spotting trailers easy. Safety is maintained through clear?communication, while avoiding injury to personnel and costly damage to loading docks, equipment and buildings. The red and green LED lights?are instantly understood as Stop and Go, providing clear signals to dock attendants inside the building and truck drivers outside the building.

Interior 12 V/24 V universal

Control entry to parking garages, loading dock areas and drive-thru or any high traffic areas

Guide trucks backing into loading docks

Warn workers and drivers of hazardous situations; ; FEATURES

LEDs provide up to 100?000 hours or 10 years of continuous use

LEDs provide a high quality light with no glare

Uses 30% less energy then conventional incandescent guide light units

Recessed LED’s are shock, vibration and temperature proof and produce no heat

Service/maintenance free, no need to replace bulbs or lenses

Will not rust, pit or corrode; ; SPECIFICATIONS

Operating and storage temperatures range from -40C to 85C

Embedded wiring on the back of the panel makes the lights moisture, water and weather resistant

Each light fixture includes a 15′ long wiring cable and requires 12 V or 24 V AC, 0.2 A

110 V

Pre-drilled mounting holes provide easy installation

Certified for sale in Canada by an accredited certification body Note: When purchasing a system (inside/outside) for 110 V install, the interior model XC798 at 110 V is only required. This unit will accept the 24 V from exterior unit. As a system the outside MUST be 24 V, the only time one would need a 110 V outside is if they are plugging into another control box that outputs only 110?

Using the Sure-Dock system truck drivers can safely center their truck and/or trailer between the Sure-Dock panels.
Panels sold individually.
