IPC2325EBR5-DUPZ

Camera

Sensor

1/2.7″, progressive scan, 5.0megapixel, CMOS

Lens

2.7~13.5mmAF automatic focusing and motorized zoom lens

DORI Distance

Lens

Detect(m)

Observe(m)

Recognize(m)

Identify(m)

2.7mm

60.8

24.3

12.2

6.1

13.5mm

303.8

121.5

60.8

30.4

Angle of View(H)

93.38 ~ 28.56

Angle of View (V)

88~ 16.4

Angle of View (O)

121.4~33.7

Adjustment angle

Pan: 0~360

Tilt: 0~90

Rotate: 0~360

Shutter

Auto/Manual, shutter time: 1~1/100000 s

Minimum Illumination

Colour: 0.002 Lux (F1.2, AGC ON)

0 Lux with IR on

Day/Night

IR-cut filter with auto switch (ICR)

Digital noise reduction

2D/3D DNR

S/N

>52 dB

IR Range

Up to 50m (164 ft) IR range

Defog

Digital Defog

WDR

120dB

Video

Video Compression

Ultra 265,H.265, H.264, MJPEG

H.264 code profile

Baseline profile, Main Profile, High Profile

Frame Rate

Main Stream:5MP(2592 x 1944): Max. 20 fps, 5MP(2592 x 1944): Max. 25 fps(WDR OFF), 4MP(2560 x 1440): Max. 30 fps, 3MP(2048x 1536): Max. 30 fps, 2MP(1920 x 1080): Max. 30 fps;

Sub Stream:2MP(1920 x 1080): Max. 30 fps;

Third Stream:D1(720 x 765): Max. 30 fps

9:16 Corridor Mode

Supported

HLC

Supported

BLC

Supported

OSD

Up to 8 OSDs

Privacy Mask

Up to 8 areas

ROI

Up to 8 areas

Motion Detection

Up to 4 areas

Smart

Behavior Detection

Intrusion, cross line, motion detection

Intrusion

Enter and loiter in a pre-defined virtual region

cross line

Cross a pre-defined virtual line

motion detection

Moving within a pre-defined virtual region

Recognition

Face detectionAudio detection

?
