3M Fire Barrier Cast-in Device Metal Deck Adaptor, 3MDA, 3 in (7.6 cm)

The 3M Fire Barrier Cast-in Device Metal Deck Adaptor 3MDA is used in conjunction with a 3-inch (76.2 mm) 3M Fire Barrier Cast-In Device

It allows the device to be installed on fluted metal decks (requires a minimum 2-1/2 in

(63.5 mm) concrete topping).

Product Information

Brand	3M
Color	Red
Fire Rating	3 Hour
Origin Country	USA
Product Type	Fire Barriers
Size	3 Inch

Extra Product Information

The 3M Fire Barrier Cast-in Device Metal Deck Adaptor 3MDA accommodates both metallic and non-metallic models of 3M Fire Barrier Cast-In Device

It is firestop tested for up to 3 hours, when used in conjunction with the appropriate 3M Fire Barrier Cast-In

Product Information

Easily snaps into place on device without additional fastening

Factory made, helps assure consistent quality

Firestop tested for up to 3 hours, when used in conjunction with the appropriate 3M Fire Barrier Cast-In Device, in accordance with ASTM E 814 (UL 1479)

For use with up to 2 inch diameter (38.1 mm to 152.4 mm) metallic or non-metallic pipe penetrations

Red colour easily identifiable as fire-rated

UL Classified, universally recognized independent test agency

Suggested Application

Typically used in new installations when the floor assembly is concrete poured over a fluted metal deck
