3M Fire Barrier Cast-in Device Height Adaptor, 3HA, 3 in (7.6 cm)

The 3M Fire Barrier Cast-In Device Height Adaptor 3HA is to be used in conjunction with a 3 inch (76.2) 3M Fire Barrier Cast-In Device

It increases the height of allowable concrete thicknesses by 4 inches (101.6 mm) for installations requiring up to 12 inches (304.8 mm) pour depths.

Product Information

Brand	3M
Fire Rating	3 Hour
Origin Country	USA
Product Type	Fire Barriers

Extra Product Information

The 3M Fire Barrier Cast-In Device Height Adaptor accommodates both metallic and non-metallic models of 3M Fire Barrier Cast-In Device

This height adapter snaps easily onto device, and the device is then secured to metal deck (see system details for inst

Product Information

Adds up to 4 inches (101.6 mm) to height of device

Factory made, helps assure consistent quality

Firestop tested for up to 3 hours, when used in conjunction with the appropriate 3M Fire Barrier Cast-In Device, in accordance with ASTM E 814 (UL 1479)

For special applications, can be modified to accommodate larger depths of concrete pour

Red colour easily identifiable as fire-rated

UL Classified, universally recognized independent test agency

Suggested Application

Typically used in new installations when the concrete slab thickness will be greater than 8 inches (203.2 mm)
